Furnace 35 Data Sheet

Furnace 35 (IHO) Technical Data


Product Specification:


Furnace 35 Industrial Heating Oil

Class D





Characteristics Units Minimum Maximum
Density @ 15 ˚C Kb/m3 820 875
Viscosity @ 40 °C cSt 1.5 5.5
Carbon residue (micro) 10% Bottoms %m/m <0.1 0.3
Distillation Rec @ 350˚C / Rec @ 250˚C %vol 85.0 65.0
Flash Point (PMCC) ˚C 56.0 75.0
Calorific Value MJ/L – 42.4
Sulphur %m/m 0.08 0.10
Copper Corrosion (3hrs @ 100˚C) Class 1 1
Cold Filter Plugging Point ˚C -20 (typical) -4(Summer) / -12(Winter)
Fatty Acid Methyl %V/V <5% 5%
Kinematic Viscosity @ 40˚C
Winter cSt 1.5 5.5
Summer cSt 2.0 5.5
Ash %m/m – 0.01
Ester (Fame) Content Nil Nil
Water mg/kg 80 typical 200
Sediment mg/kg 15 (Typical) 24
Strong Acid Number MgKOH/g Nil Nil

Additional Information


Furnace 35 is a class D gas oil specifically designed for heating applications.


The product is FAME free so therefore is not susceptible to the storage issues presented by comparative fuels.


The product is not to be used in diesel engine applications.


The above typical values are expected qualities based on recent historical production data and should therefore not be considered a guarantee of quality
