AdBlue Data Sheet

Adblue Technical Data


Product Specification:


AdBlue:

ADBL/5 (05/15/0082001)

conforms to DIN 70070 and ISO 22241


Sales Specification Units Minimum Maximum Typical
Urea Content Weight % 31.80 33.20 32.50
Density g/cm3 1.087 1.093 1.0895
Refractive Index at 20o C 1.3814 1.3843 1.3829
Alkalinity as NH3 % – 0.2
Biuret % - 0.2
Aldehydes mg/kg – 5
Insolubles mg/kg – 20
Phosphate (PO4) mg/kg – 0.50
Calcium mg/kg – 0.50
Iron mg/kg – 0.50
Copper mg/kg – 0.20
Zinc mg/kg – 0.20
Chromium mg/kg – 0.20
Nickel mg/kg – 0.20
Aluminium mg/kg – 0.50
Magnesium mg/kg – 0.50
Sodium mg/kg – 0.50
Potassium mg/kg – 0.50

Additional Information


Storage: To maintain the product quality it is recommended that AdBlue® is stored below 25o C and out of direct sunlight.

Do not store or allow product to come into contact with mild steel, aluminium, brass, copper or alloys. These will damage the catalyst system.

Freezing: Adblue® will begin to freeze at -11o C; this does not affect the product quality or strength.

 The liquid phase of a partially frozen solution will still be at the required concentration and may continue to be used. The remaining frozen portion may be used after allowing to thaw
